The drive is equipped with a collet tool mounting for mounted tools.
The exhaust air flow of the air grinder is at the back.
The air grinder has to be used with oil.
The drive stands out thanks to its extended design and particularly slim extension.
Due to the lever throttle, the drive has a dead man’s switch.
1 m exhaust hose and 3 m air supply hose with 1/4″ male threaded connection and threaded quick coupling (STGI), 6 mm collet, 2 keys (EM size 7/16″, EM size 9/16″).
Advantages:
The extended version of the tool is suitable for working on hard-to-reach and particularly narrow areas.
Safe working using dead man’s switch.
No dust turbulence on the workpiece side.
Safety notes:
The drive must be operated with the specified number of oil droplets in order to prevent premature malfunctioning.
PFERDERGONOMICS:
PFERDERGONOMICS recommends the drive to improve comfort when working.
- Air consumption (idle): 0.95 m³/min
- Air consumption (under load): 0.85 m³/min
- Air exhaust: Rear
- Collet group: 5
- Height: 46 mm
- Horsepower: 600 Watt
- Included Ø collet [mm]: 6 mm
- Inner diameter of air inlet hose: 8.5 mm
- Length metric: 335 mm
- Net weight: 1.17 kg
- Number of laps: 22000 RPM
- Number of oil drops [min]: 5 Tropfen
- Valve version: Lever
- Versioning: Especially slim extension
- Width metric: 46 mm
- Working pressure: 6.3 bar
