Availability: 9 in stock
Type:NEMA 4X Type: Nonmetallic Enclosure Special Features:Raised, hinged snap latch Type:, overlapping and opaque cover design with FIP formed-in-place polyurethane gasket system Application:Industrial control panels intended for general industrial use, operating from a voltage of 600 volts or less Material:ULTRAGUARD – Fiberglass reinforced polyester – thermoset Size:A=10.14, B=8.26, C=6.13 plus 1.75 raised cover, usable depth=7.21 Color:RAL 7035 – Gray Mounting:Stainless steel feet fastened to back side brass inserts
| Catalog Number | AM1086RL |
|---|---|
| Manufacturer | Allied Moulded Products |
| Brand | Allied Moulded Products |
| Country of Origin | United States |
| Made in USA | Yes |
| Application | Industrial control panels intended for general industrial use, operating from a voltage of 600 volts or less |
| Construction | Compression molded |
| Cubic Capacity | 660 cu. In. (.38 cu. Ft.) |
| Insulation | Nonconductive nonmetallic |
| Material | ULTRAGUARD – Fiberglass reinforced polyester – thermoset |
| Mounting | Stainless Steel Feet Fastened To Back Side Brass Inserts |
| Special Features | Raised, hinged snap latch type, overlapping and opaque cover design with formed-in-place polyurethane gasket system |
| Standard | UL 508A – Industrial Control Panels |
| UPC | 085339911029 |
| GTIN | 00085339911029 |
| Item Type | NEMA 4X Type Nonmetallic Enclosure |
| Size | A=10.14″, B=8.26″, C=6.13″ plus 1.75″ raised cover, usable depth=7.21″ |
